Workmaster Plate for Kubota BX 48" QA (quick attach) bucket. 2017-current
SKU: BXQA
$239.00 Bolt On, Powder coated with predrilled holes, all grade 8 hardware included.
Click HERE for Installation Video.
For all Kubota BX models with QA (Quick attach) buckets with model number BX2448 ONLY
(The model number of your bucket is located on the backside of the bucket on a sticker ( See last picture)
(This WILL NOT WORK if you have a “Pin on” bucket. Please see our “BXPin on” workmaster plate if you have a pin on bucket
Fits all Kubota BX series with 48” QA (quick attach) buckets
commonly found on Kubota models:
2017 and newer BX 1880, 2380, BX2680, BX23S
Features:
22” L x 6” W x 1/4” thick steel plate formed on the front leading edge for increased strength
(2) 5/16” Forged in USA grab hooks (G70) rated at 4700lbs WLL (Accepts 3/8” chain and under)
(2) 5/8” Tow/Grab Handles (5000lb WLL)
(1) 2” receiver with 5/8” center hole
Laser cut, CNC formed, Mig welded
Full Industrial Grade E-Coat and Powder coat
All grade 8 hardware included
Installation time: 25-30min
Instructions for mounting
The Workmaster Plate is the perfect addition to your tractor for the hobby farm enthusiast, from moving around small trailers to lifting awkward materials and pulling those unwanted shrubs out to safely securing your tractor during transport, you will always find a job for the workmaster plate!
